High Peak Combination Tent

Top grate glass sidewalls high peak combination tent is top welcome by the high grade gorgeous outdoor events. Derivative of standard 'A frame' tents by adding an additional high peak system. Accessories of Glass windows sidewalls, plain pvc sidewalls, clear windows sidewalls are available. Elegant designed glass walls high peak combination tent is widely used for outdoor exhibitions,wedding parties,festival celebrations,conferences,sports events,outdoor shops and so on. Special outer shape is top welcome by the nigh grade gorgeous outdoor events.



Transparent high peak combination tent
Transparent high pea..
Transparent high pea..
12X22m high peak and Multi-sided Tents combination – WS series
12X22m high peak and..
12X22m high peak and..
High peak wedding tent with decoration lining [MS series]
High peak wedding te..
High peak wedding te..


Available sizes:
  • Clear Span available from 3m to 60m.
  • Length adjustable by 3m unit(SS & WS series) or 5m unit (for other series).
    • Features:
  • Derivative of standard 'A frame' tents by adding an additional high peak system.
  • Can be combined with standard A frame,and/or 1/2 multi-sided tents at two ends freely to get special and elegant appearance.
  • No exterior guy ropes or staking required.
  • No poles inside, 100% interior space can be used.
  • Relocatable,easy to install,dismantle and transport.
  • Full line accessories available.
    • Frame:
  • No maintenance required.
  • Extruded 4 channel aluminum hollow profiles with anodized finishing above 12um.
  • All steel connectors including small parts have galvanized finishing above 60um.
  • Modular character for diverse combination and expansion.
    • Technical Parameters:

    Style Type Span（m） Length（m） Side height（m） Ridge height（m） Roof Pitch Wind Load
    （km/h）    		 Get A Quote
    SS SS6/2.6-HPC 6 17.2 2.6 5.2 20° 100 Inquiry
    SS8/2.6-HPC 8 19 2.6 5.8 20° 100 Inquiry
    SS10/2.6-HPC 10 20.6 2.6 6.6 20° 100 Inquiry
    Main Profile Size: 100x48x3mm

    Style Type Span（m） Length（m） Side height（m） Ridge height（m） Roof Pitch Wind Load
    （km/h）    		 Get A Quote
    WS WS8/2.6-HPC 8 19 2.6 5.8 20° 100 Inquiry
    WS10/2.6-HPC 10 20.6 2.6 6.6 20° 100 Inquiry
    WS12/2.6-HPC 12 22.4 2.6 6.8 20° 100 Inquiry
    Main Profile Size: 122x68x3mm

    Style Type Span（m） Length（m） Side height（m） Ridge height（m） Roof Pitch Wind Load
    （km/h）    		 Get A Quote
    MS MS10/3.3-HPC 10 28.6 3.3 7.3 20° 100 Inquiry
    MS12/3.3-HPC 12 30.4 3.3 7.5 20° 100 Inquiry
    MS15/3.3-HPC 15 35 3.3 8.3 20° 100 Inquiry
    Main Profile Size: 152x120x4mm

    Style Type Span（m） Length（m） Side height（m） Ridge height（m） Roof Pitch Wind Load
    （km/h）    		 Get A Quote
    BS BS15/4-HPC 15 35 4 9 20° 100 Inquiry
    BS20/4-HPC 20 39 4 10.5 20° 100 Inquiry
    Main Profile Size: 204x120x4mm

    Style Type Span（m） Length（m） Side height（m） Ridge height（m） Roof Pitch Wind Load
    （km/h）    		 Get A Quote
    XLS XLS20/4-HPC 20 39 4 10.5 20° 100 Inquiry
    XLS25/4-HPC 25 49 4 12 20° 100 Inquiry
    XLS30/4-HPC 30 50 4 12.8 20° 100 Inquiry
    Main Profile Size: 152x120x4mm
